20 HP Rotary Screw Air Compressor — 15 kW, 10 Bar
Oil-injected rotary screw air compressor — 15 kW, 2.5 m³/min at 10 bar.
Description
20 HP rotary screw air compressor with 15 kW IE3 motor, 2.5 m³/min flow at 10 bar, belt drive and ≤72 dB(A) noise level. Ideal for workshops, small factories and CNC lines that need continuous-duty compressed air.
Technical Specifications
Key Features
3-year warranty — Rotary screw compressors
Namerah Industrial Co. supplies this AirVini rotary screw compressor.
Not sure of the right size? Try the CFM calculator. Need a custom-built tank instead? See custom pressure vessels, or check our installation & maintenance service.
Pricing: Contact for Quote
Frequently Asked Questions
How much air (CFM / m³/min) does a 20 HP screw compressor deliver?
This 20 HP unit delivers 2.5 m³/min (≈88 CFM) of free air at 10 bar working pressure — enough for 3–5 medium pneumatic tools running continuously or a small CNC / paint booth.
Why is 10 bar the right working pressure?
Most pneumatic tools and paint guns are rated for 6–8 bar at the point of use, and 10 bar at the compressor provides roughly 25% headroom for pressure drop across hoses, filters and dryers.
What tank size should I pair with a 20 HP screw compressor?
For continuous applications pair with a 500–1000 L air receiver tank; the tank smooths pressure fluctuations, reduces motor cycling and extends compressor lifespan.
Screw vs piston at 20 HP — which should I choose?
A screw compressor is designed for continuous duty (100% duty cycle), runs quieter and produces cooler, more consistent air. With more than 4–8 hours of daily use screw is the right choice; piston is only preferred for intermittent workshop use.
What is the warranty and service coverage?
The screw compressor warranty is 3 years. Supply, installation and maintenance are available within Saudi Arabia.
